APX-3442
Dual-Channel 10Gig.E Interface Board
| Model | APX-3442 |
| Image Input Interface | ◎RJ45 ×2ports ◎100MBaseT/1GBaseT/10GBaseT |
| PoE | IEEE 802.3af ※1: 30W max per channel |
| 2ports 10GbE Controller | ELX550AT2 |
| System Bus | PCI Express3.0(Gen3) 8.0GT/sx 4 |
| Power Supply | +12V±8% |
| Current Consumption | +12V(2.1A) ※2 |
| Operating Environment | Temperature: 0°C ~ 50°C Humidity: 30% ~ 85% (non-condensing) |
| Dimensions | 168mm × 112mm Panel Width: 20mm (excluding the connector part) |
| Weight |
180g |
| Supported OS | Windows 10 (64bit) |
| Software | Capture: Intel driver and drivers provided by camera/software vendors |
※1: A non-PoE type model, APX-3442-1, is also available.
※2: PoE power supply is excluded; power for PoE is provided via a 6-pin connector.
Notes)
– The specifications and appearance stated are subject to change without notice.
– Power consumption does not include inrush current.
– In order to use the product correctly, be sure to read the instruction manual before using the product. Also, use the product under the conditions applicable to your product warranty.
